LED BAR 180° 24V for stretch ceiling backlighting
The message will already contain this product's name and code.
*The prices shown are for information purposes only and do not constitute a commercial offer within the meaning of Art. 66 §1 of the Civil Code of the Republic of Poland. The exact quotation is always determined individually after a request for quotation has been submitted and reviewed, or after an inquiry sent directly by email.
A rigid LED bar for stretch ceiling backlighting, powered by 24V DC. Lenses spread the light at a 180° angle. Two power ratings, 6.6 W and 9.18 W, and three colour temperatures: 3000K, 4000K and 6500K.
Installation example: the bars are laid in parallel about 12 cm apart, with 24V supplied by two power lines.
Product features:
- Length: 960 mm, width: 18 mm
- LEDs: 12 × SMD 2835 with lenses, 80 mm pitch
- Beam angle: 180°
- Supply: 24V DC
- Power: 6.6 W or 9.18 W
- Luminous efficacy: 130 lm/W
- Colour temperature: 3000K, 4000K, 6500K
- Cutting step: 160 mm
- Series connection: up to 10 bars
- Ingress protection: IP20
- Operating temperature: −25 to +60 °C
| Power / voltage | 6.6 W / 24V, 9.18 W / 24V |
|---|---|
| Light colour | 3000K, 4000K, 6500K |
| Beam angle | 180° |
| Luminous flux (~lm/W) | 130 |
